Signode TABLE-TYER - Roller Arm Assembly; Tension Arm and Shafts; Rollers and Bearings; Fasteners and Bushings

12/14/10
ROLLER ARM ASSEMBLY
KEY QTY PART NO. DESCRIPTION
1
1
500607
Tension Arm
2
1
500508
Shaft
3
1
500609
Connect Rod
4
1
500610
Roller Arm
5
1
500611
Shaft
6
1
500612
Spring
7
1
500613
Roller Shaft
8
1
500614
Roller
9
1
430705
Feed Spring
10
1
500616
Washer
11
1
500617
Nut
13
1
500619
HBS, M6x75
14
1
500620
HN, M6
15
2
500495
HBS, M6x16
16
3
500508
SW, M6
17
2
500621
Bearing, 6001ZZ
18
1
500622
Snap Ring S12
19
1
500505
HSS, M5x5
20
1
500623
HBS, M5x40
21
1
500624
Bearing, 635ZZ
22
3
500499
PW, M5
23
4
500563
HN, M5
24
2
500500
SW, M5
25
2
500625
Snap Ring E6
26
2
500626
Bushing
27
1
500627
HBS, M5x30
28
1
430718
Spacer
31
1
430719
PW, M6 (C)
