12/14/10
CONTROL HEAD GROUP ASSEMBLY
KEY QTY PART NO. DESCRIPTION
1 1 500475 Main Body Block
2 1 500476 Switch Lever
3 1 500477 Switch Pin
4 1 500478 Strap Guide (A)
5 1 500479 Strap Guide (B)
6 1 500480 Switch Bracket
7 1 500481 Cutter Holder
8 1 500482 Bar Guide Lid
9 1 500483 Spring Hook
10 1 500484 Shaft
11 1 500485 Arm
12 1 500486 Return Spring
13 2 500487 Collar
14 1 500488 Slide
15 1 500489 Separator
16 1 500490 Guide (L)
17 1 500491 Guide (R)
18 1 500492 Gum
19 1 500493 Front Plate
20 1 500494 Guide Front
21 4 500495 HBS, M6x16
22 4 500496 HBS, M5x12
23 1 500497 HBS, M5x25
24 1 500498 Bearing 635ZZ
25 4 500499 PW,M5
26 1 500500 SW,M5
27 2 500501 HN, M5
28 1 500502 PMS, M4x20
29 1 500503 HN,M4
30 1 500504 Spring Pin, 6x20
31 2 500505 HSS, M6x6
32 2 500506 HN,M8
33 1 500507 SW,M8
34 4 500508 SW,M6
35 3 500509 Spring Pin, 3x12
36 1 500510 HBS, M5x5
37 1 500511 HBS, M4x25
38 3 500512 HBS, M5x16
39 2 500513 HBS, M5x8
41 1 500514 Cam Group
42 1 430733 Assy
43 1 500516 Rear Bar Assy
44 1 500517 Press Bar Assy
45 1 500518 Front Bar Assy
46 1 500519 Transmission Group
51 1 500520 HBS,M5
52 2 500521 PMS, M3x20
53 3 500522 Micro Switch
54 2 500523 PW, M3
55 4 500524 SW, M3
56 2 500525 HN, M3
57 2 500526 PW, M4
58 2 500527 SW, M4
59 2 500528 PMS, M4x12
60 1 500529 Snap Ring E3
16
