2-14
Paper flange
How to detach the paper rolls
1 Pull out the Roll 1 or Roll 2 drawer.
Use your fingers to grasp the handle in the
center of the drawer and pull the drawer out
gently.
(The diagram indicates a case where the Roll 2
drawer is opened.)
2 Rewind the paper roll and then remove it.
Turn the paper flange in the direction indicated
in the diagram and continue to rewind the roll
until you see the end of roll. Lift up the paper
flange and remove the paper roll.
To Next Page
