AP10S
Documentation English
AP10S · Date 15.04.2020 · Art. No. 87100 · Mod. status 83/20
23
1 Documentation
The following documents describe this product:
• The data sheet describes the technical data, the dimensions, the pin
assignments, the accessories and the order key.
• The mounting instructions describe the mechanical and electrical
installation including all safety-relevant requirements and the associ-
ated technical specifications.
• The user manual and software description for commissioning and inte-
grating the position indicator into a fieldbus system.
These documents can also be downloaded at "http://www.siko-global.
com/p/ap10s".
2 Safety information
2.1 Intended use
Together with an external sensor, the electronic position indicator AP10S
constitutes a high-precision measurement system. The position indica-
tor serves exclusively for processing and output of position values, pro-
cessing and providing measured values as electronic output signals for an
upstream control as well as for the display of target values and positioning
aids. The AP10S must be used for such purposes exclusively.
1. Observe all safety instructions contained herein.
2. Arbitrary modifications and changes to this position indicator are for-
bidden.
3. Observe the prescribed operating and installation conditions.
4. Operate the position indicator exclusively within the technical data
and the specified limits (see chapter 9).
5. This product are intended for installation in NFPA 79 applications only.
2.2 Identification of dangers and notes
Safety notes consist of the signal symbol and a signal word.
Danger classes
Immediate danger that may cause irreversible bodily harm resulting in
death, property damage or unplanned device reactions if you disregard
the instructions given.
DANGER
