AP10S
Commissioning English
AP10S · Date 15.04.2020 · Art. No. 87100 · Mod. status 83/20
34
Configuration parameters RS485
Parameter Value range Default Meaning/Remark
ID 1 ... 127 31 bus address
NOTICE
Restart is required after chang-
ing these parameters!
KBAUD 19.2, 57.6,
115.2
57.6 SIKONETZ baud rate (e. g.
57.6kbit/s)
Protcl SN5, SEruic SN5 SIKONETZ protocol
bUS to 0 ... 20 0 Bus Timeout
Inhibt 0 ... 10 0 Response delay
CODE 0 ... 999999
000100
011100
0 for test/diagnosis purposes
start alignment travel (see chap-
ter 5.2)
load factory settings
Configuration parameters IO-Link
Parameter Value range Default Meaning/Remark
CODE 0 ... 999999
000100
011100
0 for test/diagnosis purposes
start alignment travel (see chap-
ter 5.2)
load factory settings
5.1 Sensor
Mounting of the sensors as well as installation of the sensor cable is exp-
lained in the documentation pertaining to the sensor MS500H or GS04.
With 24V supply voltage operation the display controls the connected sen-
sor. If no sensor is connected or if sensor is detached from the magnetic
tape, this is interpretated and displayed as "Error" (blinking display). Even
after an interruption of the voltage supply, the "Error" display will persist.
In this case, please check sensor connection / position. Then carry out calib-
ration (see key functions) for eliminating the "Error" display.
If both battery supply and power supply fail simultaneously (e. g. during a
battery change), the absolute position value can get lost. For making the
measuring system work again, calibration is required.
