Siko AP10S Series User Manual

AP10S
Technical data English
AP10S · Date 15.04.2020 · Art. No. 87100 · Mod. status 83/20
40
9 Technical data
Mechanical data Additional information
Housing plastic, reinforced plug thread nickel-plated brass
/ ground connection metal
Color black, RAL 9005
Weight ~0.11kg
Electrical data Additional information
Operating voltage 24VDC ±20%
Current consumption ~30mA if operated with LEDs, additional
~3mA per LED
Power input ~0.72VA Max. power supply of the power
supply unit used: 100VA.
The power supply used corres-
ponds to SELV/Limited Energy
(IEC 61010-1) or SELV/LPS (IEC
60950-1) or Class 2 (UL 1310).
Battery service life ~5 year(s)
Parameter memory 10
5
cycles also applies to calibration pro-
cedures
Display/display range 6 digits LCD 14-segment,
~8mm height
decimal points, 2 rows, spe-
cial characters (backlit LED red/
white)
Special character cw arrow, ccw arrow, incre-
mental measurement, battery
Status display 2x two-color LED (red/green) programmable position status
Keys incremental measurement
function, parameterizing,
resetting
Interface RS485; CANopen; IO-Link no galvanic isolation
Type of connection 2x M8 plug connectors
(A-coded)
4 pole, 1x socket, 1x pin
(RS485, CANopen)
1x M8 plug connectors
(A-coded)
4 pole, 1x pin (IO-Link)
1x M8 plug connectors
(A-coded)
6 pole, 1x socket (sensor)
grounding via flat connector
6.3mm or cable lug
System data Additional information
Scanning external sensor
