Siko AP10S Series User Manual

AP10S
Technical data English
AP10S · Date 15.04.2020 · Art. No. 87100 · Mod. status 83/20
41
System data Additional information
Resolution 720 increments/revolution displayed value/revolution
freely configurable (use with
GS04)
0.01mm use with MS500H
System accuracy ±35µm use with MS500H
Measuring range ±655m use with MS500H
≤14562 revolution(s) use with GS04
Approval UL UL 61010-1, File Nr. E503367
Ambient conditions Additional information
Ambient temperature 0 … 60°C
Storage temperature -20 … 80°C
Relative humidity condensation inadmissible
EMC EN 61326-1 immunity requirement of indus-
trial applications, emission limit
class B
Safety regulations DIN EN 61010-1 (VDE 0411-1),
UL 61010-1
Limited power supply according
to DIN EN 61010-1 Section 9.4.
Protection class II
Surge category II
Pollution level 2
Protection category IP53 EN 60529, only with mating con-
nectors (Protection category not
tested by UL)
IP65 EN 60529, only with mating con-
nectors (Protection category not
tested by UL)
Shock resistance 500m/s
2
, 11ms EN 60068-2-27
Vibration resistance 100m/s
2
, 5 … 150Hz EN 60068-2-6
