3.4 PRODUCT STRUCTURE
1
LCD Display
2
Brake light
3
Button
4
Temperature compensation sensor connector
5
Battery terminals
6
Silentwind terminals
7
Solar Panel terminals
8
Load terminals
9
External Antenna connector
10
M4 screw install hole
