Back panel:
• Power cable to be connected into # 1 Power outlet.
• Pedal to be connected into # 4 Pedal outlet (black big outlet) on the rear unit’s side.
• Red extension cable to be connected into # 5 Roller electrode outlet (red outlet) on the rear unit’s side while
other end inserted into the Soothing roller outlet.
• Black extension cable to be connected into # 6 Contact electrode outlet (black small outlet) on the rear
unit’s side, while other end is inserted into the Electrode outlet.
• Satellite to be plugged into # 7 Satellite outlet (silver outlet) on the rear unit’s side.
Front panel:
• Cable for Probe holder: thicker end to be connected into # 8 Probe Holder Connection on the front
unit’s side (insert and rotate to insure holding protection).
Now you can Turn ON the unit.
Turning the unit ON
1. To turn the unit on, use the power switch located at the back of the unit to the «ON» position (1).
2. Than menu screen will appear :
3. The unit will take few minutes to load all programs.
4. It is ready to use when the screen displays “Depilation”and “Soothing phase’’
