Silicon Graphics Octane III Component Replacement Guide

22 007-5650-001
1: Component Replacement
Installing the Tray Cover
When you have finished replacing a component, perform the following procedure to install the top
cover on the tray:
Note: If any cables to the disk drives are disconnected, be sure to reconnect them before installing
the tray cover.
1. Place the cover on top the tray so the hooks line up with the holes on the tray.
2. Push the cover downwards and slide it towards the back of the tray; refer to Figure 1-5.
3. Install the two screws that secure the cover to the tray; refer to Figure 1-5.
