Silicon Graphics Octane III Component Replacement Guide

System Fan Assembly Replacement
007-5650-001 37
System Fan Assembly Replacement
Warning: Only personnel with extensive experience repairing server hardware should
attempt to replace or upgrade components inside an SGI Octane III deskside workstation
enclosure.
Each enclosure has two sets of 6-fan assemblies to provide the main cooling for the system. One
fan assembly is located on the front of the enclosure (behind the front cover); the other fan
assembly is located on the rear of the enclosure.
Figure 1-15 Front and Rear Fan Assemblies
Front Fan Assemblies
(with Front Cover
Removed)
Rear Fan Assemblies
