13.2 Barometer Mode - Pressure History Graph for the Last 24 Hours
Pressure History Graph
!
!
!
!
!
!
The ADC is equipped with a barometric
pressure memory function. It records the last
24 hours barometric pressure readings, and
it can display them by bar-graph.
In Barometer Mode, press the [set] button to
select the Pressure History Graph Display.
While in the Temperature History Graph
Display, the right most bar will start flashing.
The right most bar represents the current
temperature (0 hour), while the other bars
represent the pressure records of the last 24
hours. Each pressure record is taken at the
hour (i.e 12:00, 1:00 and 2:00 ... ).
To browse the pressure record at different
times, press the [set] button to scroll the
record backward (from the current record to
the -24 hour record) or press the [reset]
button to scroll the record forward (from the
-24 hour record to the current record).
Press the [mode] button once to exit the
Pressure History Graph Display.
Barometer Mode
Pressure History Graph Display
[set]
[set]hold [set]
[mode]
[reset]hold [reset]
BAR
hPa
1-00
1023.2
flashing bar
represents
the selected record
(graphical bar)
0 hour (current)
-24 hour
the time that
took this record
the pressure
of the selected
record (numeric)
Select the record by
backward scrolling
from current to -24 hour
(1 hour per step)
Select the record by
forward scrolling from
-24 hour to current
(1 hour per step)
Select the lap time by
backward scrolling
(fast scrolling)
Select the lap time by
forward scrolling
(fast scrolling)
BARO hPa
1001.3
