23
GB
1. Overview
1 Lid with lid bracket
2MAX Marking in frying basket (maximum filling level)
3 Frying basket
4 Metal bracket of the handle
5 Button for adjusting the handle
6 Handle
7 Oil container (integrated into deep fryer)
8 Button for opening the lid
9 Deep fryer
10 Orange LED: operation control light (is lit when the device is switched
on)
11 Green LED: temperature control light (is lit when the set temperature has
been reached)
12 O/I On/off switch
13 Temperature specifications for food
14 Temperature control
15 Carrying recesses of the deep fryer
16 Reset Button (is released after overheating)
17 Holder for mains plug
18 Power cable with mains plug
19 Pouring recess for oil
20 MIN/MAX Markings in oil container (minimum/maximum filling level)
21 Locking mechanisms for the lid
22 Oil filter (integrated into lid)
23 Openings in the lid
24 Recess for lid bracket
__326314_Fritteuse_B8.book Seite 23 Dienstag, 24. September 2019 8:23 08
