SKR 800 C3
Description of components
(See fold-out page for illustrations)
A. Front
1 −VOLUME+ | /FUNC. dial (with button function)
2 button
3 button
4 Display
5 AUX connection (3.5 mm Ø jack socket)
6 PRESET − button
7 PRESET + button
8 −TIMER+ dial (with button function)
9 SEARCH + button
0 button (settings menu)
q
|
ST/MO button
w SEARCH − button
e
|
AMS button
r DIMMER button
t SNOOZE
|
SLEEP button
z
|
MEM button
B. Rear
u Mounting plate
i Wire aerial for FM reception
o Power cable
C. Underside
p Adjustable foot (fold-out)
a LED light
s Loudspeaker
d
Battery compartment
D. Accessories
f Spacer (for under-cabinet installation)
g Mounting screw (long)
h Mounting screw (short)
