SimCom SIM5320AL User Manual

Smart Machine Smart Decision
SIM5320AL_User Manual_V1.01 2014-08-20
16
Table 2: Pin definition
Pin No. Define Pin No. Define
1 GND 2 GND
3 POWER_ON 4 RESET
5 GND 6 SPI_CLK
7 SPI_MISO_DATA 8 SPI_MOSI_DATA
9 SPI_CS_N 10 GND
11 USB_VBUS 12 USB_DM
13 USB_DP 14 GND
15 RESERVED 16 RESERVED
17 USIM_DATA 18 USIM_RESET
19 USIM_CLK 20 V_USIM
21 NC 22 NC
23
NC
24
NC
25 NC 26 NC
27 KEYSENSE_N1 28 KEYSENSE_N0
29 KEYPAD_0 30 KEYPAD_2
31 KEYSENSE_N2 32 KEYSENSE_N3
33 KEYPAD_1 34 KEYPAD_4
35 KEYPAD_3 36 KEYSENSE_N4
37 GND 38 VBAT_BB
39 VBAT_BB 40 GND
41 GND 42 VRTC
43 GND 44 VREG_AUX
45 CURRENT_SINK 46 ADC2
47 ADC1 48 GPIO44
49 GPIO40 50 GPIO43
51 GPIO1 52 GPIO41
53 GPIO42 54 GPIO4
55 I2C_SCL 56 I2C_SDA
57 GND 58 GND
59 MAIN_ANT 60 GND
61 GND 62 VBAT_RF
63 VBAT_RF 64 GND
65 GND 66 UART_RTS

SimCom SIM5320AL Specifications

General

Brand	SimCom
Model	SIM5320AL
Category	Control Unit
Language	English
