SimCom SIM5320AL User Manual

Smart Machine Smart Decision
SIM5320AL_User Manual_V1.01 2014-08-20
17
67 UART_CTS 68 UART_RXD
69 UART_RI 70 UART_DCD
71 UART_TXD 72 UART_DTR
73 NC 74 NC
75 NC 76 NC
77 GND 78 GND
79 GPS_ANT 80 GND
2.2 Pin description
Table 3: Pin description
Pin name I/O Description Comment
Power Supply
VBAT_RF/VBAT_BB Power supply voltage
VRTC I/O Power supply for RTC
If it is unused, keep open.
VREG_AUX O LDO power output
GND Ground
Power on/off
POWER_ON I
POWER_ON should be pulled low at
least 64ms to power on or 500ms to
power off the module.
Audio interface
MIC1P
I Differential audio input
If it is unused, connect to
ground through a 100N
capacitor.
MIC1N
EAR1P
O
Differential audio output
If these pins are unused，
keep open.
EAR1N
SPK_P
O
SPK_N
USIM interface
V_USIM O
Voltage Supply for SIM card
Support 1.8V or 3V SIM card
All signals of SIM
interface should be
protected against
ESD/EMC.
USIM_DATA
I/O
SIM Data Output/Input
USIM_CLK
O
SIM Clock
USIM_RESET
O
SIM Reset
SPI interface
SPI_CLK O SPI clock
If it is unused, keep open.
SPI_CS_N O SPI chip-select
