SimCom SIM7600V-H

Smart Machine Smart Decision
SIM7600V-H_User Manual_V1.00 2018-02-24
13
Table 3: Pin Definitions
Pin No.
Pin name
Pin No.
Pin name
1
GND
2
GND
3
PWRKEY
4
RESET
5
GND
6
SPI_CLK
7
SPI_MISO
8
SPI_MOSI
9
SPI_CS
10
GND
11
USB_VBUS
12
USB_DN
13
USB_DP
14
GND
15
VDD_1V8
16
USB_ID
17
USIM_DATA
18
USIM_RST
19
USIM_CLK
20
USIM_VDD
21
SD_CMD
22
SD_DATA0
23
SD_DATA1
24
SD_DATA2
25
SD_DATA3
26
SD_CLK
27
SDIO_DATA1
28
SDIO_DATA2
29
SDIO_CMD
30
SDIO_DATA0
31
SDIO_DATA3
32
SDIO_CLK
33
GPIO3
34
GPIO6
35
HSIC_STROBE
36
HSIC_DATA
37
GND
38
VBAT
39
VBAT
40
GND
41
GND
42
NC (RESERVED)
43
GND
44
VDD_EXT
45
ISINK
46
ADC2
47
ADC1
48
SD_DET
49
STATUS
50
GPIO43*
51
NETLIGHT
52
GPIO41
53
USIM_DET
54
FLIGHTMODE
55
SCL
56
SDA
57
GND
58
GND
59
AUX_ANT
60
GND
61
GND
62
VBAT
63
VBAT
64
GND
65
GND
66
RTS
67
CTS
68
RXD
