SimCom SIM7600V-H User Manual

Smart Machine Smart Decision
SIM7600V-H_User Manual_V1.00 2018-02-24
53
B. Coding Schemes and Maximum Net Data Rates over Air Interface
Table 39: Coding schemes and maximum net data rates over air interface
Multislot definition(GPRS/EDGE)
Slot class
DL slot number
UL slot number
Active slot number
1
1
1
2
2
2
1
3
3
2
2
3
4
3
1
4
5
2
2
4
6
3
2
4
7
3
3
4
8
4
1
5
9
3
2
5
10
4
2
5
11
4
3
5
12
4
4
5
GPRS coding scheme
Max data rata（4 slots）
Modulation type
CS 1 = 9.05 kb/s / time slot
36.2 kb/s
GMSK
CS 2 = 13.4 kb/s / time slot
53.6 kb/s
GMSK
CS 3 = 15.6 kb/s / time slot
62.4 kb/s
GMSK
CS 4 = 21.4 kb/s / time slot
85.6 kb/s
GMSK
EDGE coding scheme
Max data rata（4 slots）
Modulation type
MCS 1 = 8.8 kb/s/ time slot
35.2 kb/s
GMSK
MCS 2 = 11.2 kb/s/ time slot
44.8 kb/s
GMSK
MCS 3 = 14.8 kb/s/ time slot
59.2 kb/s
GMSK
MCS 4 = 17.6 kb/s/ time slot
70.4 kb/s
GMSK
MCS 5 = 22.4 kb/s/ time slot
89.6 kb/s
8PSK
MCS 6 = 29.6 kb/s/ time slot
118.4 kb/s
8PSK
MCS 7 = 44.8 kb/s/ time slot
179.2 kb/s
8PSK
MCS 8 = 54.4 kb/s/ time slot
217.6 kb/s
8PSK
MCS 9 = 59.2 kb/s/ time slot
236.8 kb/s
8PSK
HSDPA device category
Max data rate（peak）
Modulation type
Category 1
1.2Mbps
16QAM,QPSK
Category 2
1.2Mbps
16QAM,QPSK
Category 3
1.8Mbps
16QAM,QPSK
Category 4
1.8Mbps
16QAM,QPSK
Category 5
3.6Mbps
16QAM,QPSK
Category 6
3.6Mbps
16QAM,QPSK
Category 7
7.2Mbps
16QAM,QPSK
Category 8
7.2Mbps
16QAM,QPSK
