SIM7600V-H_User Manual_V1.00 2018-02-24
Table 33: Current consumption on VBAT Pins (VBAT=3.8V)
LTE supply current
(without USB connection)
Sleep mode Typical: 1.56
Idle mode Typical: 22
@5 MHz 22.2dBm Typical: 589mA
@10 MHz 22.7dBm Typical: 577mA
@20 MHz 22.38dBm Typical: 626mA
@5 MHz 23.05dBm Typical: 519mA
@10 MHz 23.04dBm Typical: 556mA
@20 MHz 22.83dBm Typical: 600mA
@5Mbps 22.2dBm Typical: 610mA
@10Mbps 22.1dBm Typical: 600mA
@20Mbps 22.1dBm Typical: 630mA
@5Mbps 21.9dBm Typical: 505mA
@10Mbps 22.0dBm Typical: 497mA
Module is sensitive to ESD in the process of storage, transporting and assembling. Especially,
Module is mounted on the users’ mother board, The ESD components should be placed beside the
connectors which human body might touch, such as USIM card holder, audio jacks, switches and
keys, etc. The following table shows the Module ESD measurement performance without any
external ESD component.
Table 34: The ESD performance measurement table (Temperature: 25℃, Humidity: 45%)
