SimCom SIM7600V-H User Manual

Smart Machine Smart Decision
SIM7600V-H_User Manual_V1.00 2018-02-24
37
4 RF Specifications
4.1 LTE RF Specifications
Table 21: Conducted transmission power
Frequency
Power
Min.
LTE-FDD B2
23dBm +/-2.7dB
<-40dBm
LTE-FDD B4
23dBm +/-2.7dB
<-40dBm
LTE-FDD B5
23dBm +/-2.7dB
<-40dBm
LTE-FDD B13
23dBm +/-2.7dB
<-40dBm
Table 22: Operating frequencies
Frequency
Receiving
Transmission
LTE-FDD B2
1930 ~1990 MHz
824~849 MHz
LTE-FDD B4
2110~2155 MHz
1850 ~1910 MHz
LTE-FDD B5
824～849 MHz
869～894MHz
LTE-FDD B13
777~787MHz
746~757MHz
Table 23: Reference sensitivity (QPSK)
E-UTRA
band
3GPP standard
Test value
3GPP standard
Duplex
1.4 MHz
3MHz
5MHz
10MHz
10 MHz
15 MHz
20 MHz
2
-102.7
-99.7
-98
-95
-101
-93.2
-92
FDD
4
-104.7
-101.7
-100
-97
-102
-95.2
-94
FDD
5
-103.2
-100.2
-98
-95
-99
FDD
13
-97
-94
-99
FDD
4.2 LTE Antenna Design Guide
Users should connect antennas to Module’s antenna pads through the micro-strip line or other types
of RF trace. The trace impedance must be controlled in 50Ω. SIMCom recommends that the total
insertion loss between Module and antenna should meet the following requirements:
Table 25: Trace Loss
Frequency
Loss
700MHz-960MHz
<0.5dB
1710MHz-2170MHz
<0.9dB
