6.2.9.2 Remote control CR 63
connection (optionals)
Theboilerisdesignedforconnectiontoa
remotecontrolunitCR63code8092219
coupledtoanoptionalexpansionkitcode
8092240.
Theremotecontrolunitallowsforcom-
pleteremotecontroloftheboiler,except
resettingoftheboiler.
Whenn the connection has been made
theboilerdisplaywillshowthefollowing
message:Cr.
For installation and use of the remote
control, follow the instructions in the
package.
6.2.9.3 External sensor connection
(optional)
Theboileris designed forconnection to
an external temperature sensor, sup-
plied on request (code 8094101), which
canautomaticallyregulatethetempera-
turevalueoftheboileroutputaccording
totheexternaltemperature.
For installation, follow the instruction
in the package. It is possible to make
corrections to the values read by the
alterationofPAR 4.
NOTE: Any thermostat or external con-
trol unit must be installed by an authori-
sed person in accordance with AS 30000
wiring rules.
TA
TA
TA
TA
TA
R
M
SE
M2
R2
SB
BOLLITORE
RM
VZ
VZ1
TA2
VZ2
TA1
CR
EXP
SE
CR
EXP
R
M
SE
TA
CR
EXP
SI
RM
TA1
TA2
P2
RL1
RL2
P1
P
SE
CR
EXP
RM
SE
TA2
SI
RL2
P2
P1
VM
IP
CR
EXP
TSB
RM
SE
TA
VZ
TA1
VZ1
TA2
VZ2
RM
SE
TA1
TA2
TA
P2
RL
SI
RL1
RL2
P1
P
1 BASIC SYSTEM
SYSTEM WITH A DIRECT ZONE AND ROOM THERMOSTAT, OR WITH A REMOTE CONTROL (Code 8092219),
KIT EXPANSION REMOTE CONTROL (Code 8092240) AND EXTERNAL SENSOR (Code 8094101)
Fig.15
