RACK MOUNT INSTALLATION PROCEDURE
The SDB670 Base Station is designed to be fitted in a standard 403 mm (19”) rack. This
procedure should be followed when installing all new SDB670s into a 19” racking
system.
TOOLS, TEST EQUIPMENT AND MATERIALS REQUIRED
The following Tools, Test Equipment and Materials will be required to perform this
procedure:
a. Pozidriv Screwdriver
b. 4 x M6 x 12 mm Pozidriv Retaining Bolts
c. 4 x M6 x 16 mm Pozidriv Retaining Bolts
d. 8 x M6 Nuts and Plain Washers
e. M6 Cage Nuts
f. Anritsu/Wiltron S331A Test Set
g. Earth Bonding Test Set
RACK PREPARATION
Note.
Rack runner fittings differ between the various rack manufacturers. If the procedure
described below does not apply to the type of rack being used, the procedure should
be modified to suit.
1. Ensure that the rack chosen for installation is firmly bolted together and is
securely anchored to the floor or wall to prevent overbalancing.
2. In the rack, plan out the locations of equipment before commencing
installation.
Notes:
Each SDB670 requires 2U height of rack space.
Unused space should be blanked off to prevent uncontrolled circulation of air.
If used, the associated PSU TRAY requires either 1U or 2U height of rack space and is
designed to locate adjacent to the base station.
When the SDB670 is installed into a rack, support shelves or side slide runners
should be used. These are available from Simoco Wireless Solutions and supplied as a
pair with all the necessary screws for securing them.
Doc Number: TNM-I-E-0041 Revision 1.6 Page 32
