SRP9100 ~ PMR Portable Radio User Guide
TNM-U-E-0047 Issue 1.2a Page 10 © Comgroup Australia 2010
4.5 S
END
M
ESSAGE
S
CREEN
This Screen allows the user to send a free form text message to another radio
user in a similar manner to a cell phone SMS.
M7
Send Message
Memory Entry Number
(defined by FPP)
Upon selecting the Send Message menu option with the OK button, a flashing
cursor will appear on the lower left hand corner of the screen.
Each key is labelled with up to 3 text characters. The text characters are
entered by pressing the keypad key once for the first character, twice for the
second and three time for the third.
After a short delay, the cursor will advance for the next character entry.
To move the cursor left or right, use the -/+ buttons.
To delete a character, move the cursor over the character and then press the
function key that is programmed with the Reset function.
When the message is complete, press the OK button to send it. The screen
will then ask for the address to send it to with “Enter No.” Enter the address
and then press OK. The message will be sent.
