4007ES Operator’s Manual (579-1165)
Alarm Log Overview: The Alarm Log screen contains a list of alarms that the panel has received. Refer to Figure
6 for access levels required for each option inside the Alarm Log screen.
Screen Buttons:
Scroll Up
Scroll down
Return
Figure 9. Alarm Log Screen
FIRE ALARM IN SYSTEM
Menu
Date
Time
First of 1 M1-30-0 Date Time
M1-30-0
PULL STATION FIRE ALARM
Alarm
Functions
ACK
1
Clear:
IMPORTANT: Use the Clear button only after the alarms have been
investigated.
Tap the Clear button to erase all entries in the Alarm Logs screen.
Clear
Alarm Log

Simplex 4007ES Specifications

General

Model	4007ES
Category	Fire Alarms
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Display	4.3-inch color touchscreen
Power Supply	120/240 VAC, 50/60 Hz
Network Connectivity	Ethernet, RS-232, RS-485
Addressable Points	250
Communication Protocols	MAPNET II
Notification Appliance Circuits	4 NACs
Total Points	250
Annunciation	Yes
Max Devices	250
Max Notification Circuits	4
Communication Ports	RS-232, USB
