Piezo Silence:
Tap t h e Piezo Silence button to access the Piezo Silence Menu
screen, where the On or Off buttons can be used to control the piezos
at the panel and turn the Remote Annunciator’s piezo on or off.
Cfig Download:
Tap t h e Cfig Download button to access the Configuration Menu
screen. Inside, the following functions are available:
1. Tap the Enable button to allow a job download to a remote panel.
2. Tap the Enable All button to allow a job download to all the remote
panels.
3. Tap the Disable button to disable the option of a job download to a
remote panel.
4. Tap the Revert button to access the following functions:
• Alt Cfig: Tap this button to see the details of the last job used by
the panel.
• Swap: Tap this button to swap the current job for the one used
by the panel last.
• NoSwap: Tap this button to move back to the Configuration
Menu screen.
Earth Fault Search:
Tap t h e Earth Fault Search button to access the Earth Fault
Search? screen, which can be used to test for earth faults in the
circuit. The following functions are available:
• Press the Location button to display a list of cards that can be
tested for earth faults.
• Press the IDNet button to display a list of IDNet channels that
can be tested for earth faults.
• Press the LastResults button to view the results of the last
earth fault test.
Continued on next page
Piezo Silence Menu
Off On
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Configuration Menu
Enable Enable All
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Disable
Revert
Date
Time
Earth Fault Search?
Location IDNet
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
LastResult
Date
Time
Diagnostics, Continued
To Next Page
