4007ES Operator’s Manual (579-1165)
Earth Fault Latch:
Tap t h e Earth Fault Latch button to access the Earth Latch Menu
screen, which can be used to latch intermittent earth fault Troubles to
the panel. This allows the panel to consistently display a Trouble
instead of each time it re-occurs. The following functions are available:
• Tap the Off button to disable the Earth Latch function.
• Tap the On button to enable the Earth Latch function.
• Tap the ViewRaw button to view the locations of the raw earth
faults.
NAC Miswire Test:
Tap t h e NAC Miswire Test button to access the NAC Test Menu
screen, which can be used to perform a wiring test on the Notifications
Appliance Circuits (NAC). The following functions are available:
• Tap the All button to test all the NACs at once.
• Tap the Single button to test each NAC separately.
Duplicate Device Search:
Tap t h e Duplicate Device Search button to access the Duplicate
Dev Menu screen, where On or Off buttons can be used to turn the
detection of duplicate devices on IDNet channels on or off.
Weak Answer Search:
Tap t h e Weak Answer Search button to access the Weak Answer
Menu screen, where the On or Off buttons can be used to turn the
detection of weak answering devices on IDNet channels on or off.
Continued on next page
Earth Latch Menu
