6 Compatibility and testing
This section covers the compatibility, maintenance, and testing of 4098 Sensors, Detectors, and Bases.
6.1 Compatibility for 4098 Detectors and Detector Bases
This section describes the compatibility between FACPs, detectors, and detector bases.
Table 11: 4098 Detector and Detector Base compatibility
Detectors Compatible 2-Wire
detector base
System Max. quantity
of bases on an
initiating circuit
2120 ET/FADM 25
2120 FABT/VPBT 18
2120/4100+ ZAM 20
4001 18
4002 30
4020 30
4100ES/4010ES/4007ES/4100U/4100+/4120/UT 30
4004/4005 20
4006 30
4098-9788
4098-9684
(LED base for Heat
Detectors Only)
4004/4005 High Current 30
4098-9601
4098-9602
4098-9605
4098-9612
4098-9613
4098-9614
4098-9615
4098-9683 (Relay base not used with 4004 and 4005 Low
Current systems)
1
(See note 1)
Note:
1. The relay operation cannot be guaranteed unless it is the only device on that zone.
2. The panel compatibility identification marker is the model number of the module or panel.
3. The detector compatibility identification marker is the model number found on the detector label.
4. For detailed interconnection data, see the wiring diagrams for the specific panels.
5. For additional compatibility listings, see document 579-832, 2-Wire Detector Compatibility Chart.
6.2 Compatibility for 4098 Sensors and Sensor Bases
This section describes the compatibility between FACPs, sensors, and sensor bases.
Table 12: 4098 Sensor and Sensor Base compatibility
Sensors Compatible bases Max. quantity of devices on a circuit
4098-9733
4098-9778
4098-9775
4098-9776
4098-9780
4098-9789
4098-9791
4098-9792
MAPNET II:
127 (4020), 127 (4100+), 127 (4120), 127 (4100U), 127 (4100ES), 250
(4010ES/4007ES)
Addresses 1-127
4098-9733
4098-9778
4098-9775
4098-9776
4098-9789
4098-9792
128 (CDT TrueAlarm)
Addresses 0-127
4098-9733
4098-9778
4098-9734
8
4098-9775
4098-9776
4098-9777
4098-9780
4098-9789
4098-9791
4098-9792
4098-9793
4098-9770
7
4098-9766
9
4098-9767
9
IDNET:
250 (4010), 250 (4100U), 250 (4100ES), 250 (4010ES, 4007ES)
Addresses 1-250
page 34 574-709 Rev. AP
4098 Detectors, Sensors, and Bases Application Manual
