Table 3: Heat detector models and features
Detector Model Rating or Class* Area / Language Color Code
4098-9612 (UL) 135°F (57°C) FT English —
4098-9613 (UL) 135°F (57°C) FT and RR English —
4098-9614 (UL) 200°F (93°C) FT English White
4098-9615 (UL) 200°F (93°C) FT and RR English White
4098-9616E A1 European Green
4098-9617E C European Red
4098-9618E A Australian White
4098-9619E B Australian Blue
4098-9621E D Australian Red
4098-9622E I Chinese Green
4098-9624E 134°F (56.7°C) FT Korean —
4098-9625E 134°F (56.7°C) FT and RR Korean —
4098-9626E 134°F (56.7°C) FT Taiwanese —
4098-9627E 134°F (56.7°C) FT and RR Taiwanese —
4098-9628E 190°F (87.8°C) FT Korean —
4098-9629E 190°F (87.8°C) FT and RR Korean —
4098-9630E 190°F (87.8°C) FT Taiwanese —
4098-9631E 190°F (87.8°C) FT and RR Taiwanese —
* RR abbreviates Rate-of-Rise; FT abbreviates Fixed-Temperature.
All heat detectors identified in the following table mount to a detector base, refer to 4098 Bases for more information. Use the information
in Mounting when mounting detector bases.
Table 4: Heat detector specifications
Product ID Description Application Max. Spacing
Allowed (UL)
FM
4098-9612 Fixed-Temp. Only, 135°F
(57°C)
Unusually violent temp. fluctuations and ceiling
temperatures not exceeding 100°F (38°C)
70 X 70 ft. (21 X 21
m)
RTI = Quick 20 X 20 ft.
(6.1 X 6.1 m)
4098-9613 Fixed-Temp. and Rate-of-
Rise, 135°F (57°C)
Normal temp. fluctuations and ceiling
temperatures not exceeding 100°F (38°C)
70 X 70 ft (21 X 21
m)
RTI = Quick 20 X 20 ft
(6.1 X 6.1 m)
4098-9614 Fixed-Temp. Only, 200°F
(93°C)
Unusually violent temp. fluctuations and ceiling
temperatures exceeding 100°F (38°C) but not
150° F (68°C)
70 X 70 ft.(21 X 21
m)
RTI = Quick 20 X 20 ft.
(6.1 X 6.1 m)
4098-9615 Fixed-Temp. and Rate-of-
Rise, 200°F (93°C)
Normal temp. fluctuations and ceiling
temperatures exceeding 100°F (38°C) but not
150°F (68°C)
70 X 70 ft.(21 X 21
m)
RTI = Ultra Fast 50 X
50 ft.(15.2 X 15.2 m)
3.3 4098 Bases
The 4098-9788 base is designed for use with the 4098 Series smoke and heat detectors. To use a 4 wire configuration, you must use the
4098-9682 relay base. Heat detectors require the 4098-9684 base when used with a remote LED. This section only covers the information
necessary for mounting and wiring these base configurations. Before installing these bases, make a survey of the area to be covered in
accordance with the information provided in NFPA 72. For additional information, refer to the NEMA Guide for Proper Use of System Smoke
Detectors.
CAUTION: Install the bases in this section in accordance with applicable NFPA standards, local codes, and Authorities Having Jurisdiction
(AHJs). Failure to follow these instructions can result in the detector failing to initiate an alarm condition. The manufacturer is not
responsible for detectors that have been incorrectly installed, tested, or maintained.
3.3.1 Mounting
The 4098-9788 base mounts to the following electrical boxes:
• A 4 inch, or 10.16 centimeter octagonal electrical box.
• A 4 inch, or 10.16 centimeter square electrical box.
• A single gang electrical box.
Use the 4098-9832 adapter plate kit when mounting to a 4 inch square or any surface mounted box.
page 12 574-709 Rev. AP
4098 Detectors, Sensors, and Bases Application Manual
