Installation
20221586B 81
Electrical connection
AUTOPILOT COMPUTER
MAIN PCB
RF
RF+
Rudder
Feedb.
LFI3000 Mk2
LINEAR FEEDBACK
INTERFACE
TB1
White
Brown
TB2
White
Brown
Green
Yellow
Figure 3-30 LF3000/LFI3000 Mk2 connections
