Page #32 background imageLoading...
Page #32 background image
Spare parts list | 31
3 Spare parts
AP24 Control Unit
22096614 AP24 Control Unit
22096630 Mounting kit consisting of:
22095483 Cabinet corners (6)
44165181 Screw 3,5x19 (4)
24006355 SimNet blocking plug
22096820 Optional mounting bracket
24006355 SimNet blocking plug
22096515 AP24 Weather Cover
AP28 Control Unit
22096622 AP28 Control Unit
22096630 Mounting kit consisting of:
22095483 Cabinet corners (6)
44165181 Screw 3,5x19 (4)
24006355 SimNet blocking plug
22096820 Optional mounting bracket
24006355 SimNet blocking plug
22096572 AP28 Weather Cover
Autopilot Computers
22089841 AC12 Autopilot Computer
22097166 AC12 Installation accessories
22089858 AC42 Autopilot Computer
22097125 AC42 Installation accessories
22096986 Terminal cover
44161974 Fuse blade fast acting 15A/32V Blue (AC12)
44143022 Fuse blade fast acting 30A/32V Green
(AC42)
