Technical specifications | 41
Figure 4-5 AC12/AC42 Cable retainer
4.5 FC40 Fluxgate Compass
Dimensions:.....................................................See Figure 4-6
Weight: ..........................................................0,9 kg (2,0 lbs)
Material:................................................................ Black ABS
Environmental Protection:................................................ IP56
Temperature range:
Operation:.......................0 to +55 °C (+32 to + 130 °F)
Storage:........................–30 to +70 °C (–22 to +158 °F)
Supply and interface:....................................8-16V via SimNet
Power consumption:...................................................... 1,4 W
SimNet Network load factor (NL): ..........................................3
SimNet ports (input/output): ................................................1
Cable supplied:............ 5.5 m (18’) SimNet cable with connector
Mounting:....................................................Deck or bulkhead
Automatic Performance:
Calibration: ......Automatically activated from control head
Gain control:.............Automatically adjusted continuously
Deviation control:.......................................... Automatic
Static Performance:
Roll/Pitch: ...........................................................± 35°
Accuracy:.......................................± 3° after calibration
Repeatability: .....................................................± 1.0°
