| 53

System conguration | AP70/AP80 Installation Manual

Transition to HI work proﬁle with

increasing speed: 10 kn

Transition speed set to 9 kn

Transition to LO work proﬁle

with decreasing speed: 8 kn

HI work proﬁle

LO work proﬁle

• Range: OFF - 40 (kn)

• Default: OFF

Thruster inhibit speed

This feature will block the thruster from running above a set vessel speed. It is a safety feature

to prevent, especially electrical on/oﬀ thrusters, from overheating if out of water or for

instance a planing boat or in rough weather.

When the speed exceed the set limit the truster indication will change as shown below.

Thruster(s) in use Thrusters unavailable when

speed exceed inhibit limit

¼ Note: The Thruster inhibit limit will only apply when speed source is Log or SOG, not if the

speed is set manually.

• Range: 1 - 40 (kn)

• Default: 6 (kn)

Low speed limit

Sets the limit for the low vessel speed alarm.

An alarm occurs when the vessel’s speed goes below the selected limit.

• Range: 1 - 20 (kn)

• Default: 1 (kn)

Init rudder

Deﬁnes how the system moves the rudder when switching from power steering to an

automatic mode:

- Midships moves the rudder to zero position.

- Actual maintains the rudder oﬀset, and use this as trim value (bumpless transfer)

¼ Note: Actual is only available with rudder feedback signal available.

• Default: Midships
