Specications | AP70/AP80 Installation manual
Computer boards
SI80 AC70 SD80 AD80
NETWORKING
NMEA 0183, IEC
61162-1, IEC 61162-2,
input
4 ch 1 ch
NMEA 0183, IEC
61162-1, IEC 61162-2,
output
4 ch 1 ch
NMEA 0183, IEC
61162-1, IEC 61162-2,
baud rate
4.8 & 38.4
kBaud
4.8 & 38.4 kBaud
CAN bus x x x x
POWER
Local supply
12/24 V DC
+30 - 10%
12/24 V DC +
30 - 10%. Need
12 V CAN supply
N/A N/A
Consumption local
supply
0,3 - 5 A
CAN
bus load
dependent
100/65 mA
at 12/24 V
DC + load of
connected
equipment
(motor,
solenoids, clutch
etc.)
N/A N/A
NMEA 2000 Load
Equivalent number
(50 mA)
1 1 2 2
Output for CAN bus
supply
15 V DC, +/- 5%, 4 A max
INTERFACE
Reversible motor
control of rudder/
thruster
N/A
Max continuous
load 30 A, peak
50 A for 1 sec
N/A N/A
On/off solenoid
control of rudder/
thruster
N/A
12/24 V DC,
common lo, load
range 10 mA to
10 A.
(Off state
<1 mA)
Externally
supplied 12/24 V
DC, common hi
or lo, load range
10 mA to 10 A.
(Off state
<1 mA)
N/A
Analog voltage
control of rudder/
thruster, internal
supply
N/A N/A N/A
Range ±10 V,
max load 5 mA
Analog voltage
control of rudder/
thruster, external
supply
N/A N/A N/A
"Supply range:
5-24 V DC
Control range:
5-95% of
supply range
with zero ref at
min or half ref.
voltage, max
load 5 mA"

Simrad AP70 Specifications

General

Type	Autopilot Control Unit
Power Supply	12/24 V DC
Operating Temperature	-15°C to +55°C
Waterproof Rating	IPx6
Interface	NMEA 0183, NMEA 2000
Operating Voltage	12/24 V DC
Water Resistance	IPx6
Display	LCD
Control Modes	Auto, Nav, Wind
Storage Temperature	-25°C to +70°C
