GOTO
Position
Water
PLOT
Input: INTERNAL ONLY
Group selection: SIMRAD
Source (multiple available):
Simrad CE34-1 ,Sn:100003
NMEA0183 output:
Autopilot sentence ‘B’: APB ON
Bearing & distance to WP: BWR OFF
Recom. min. nav. info: RMB ON
Cross-track error: XTE OFF
UTC & time to dest.WP: ZTG OFF
MENU
Exit Accept
ENT
Navigation
Chapter 8-12 CE34/44/54 Setup menu
chapter 5.
The ship symbol will now ‘sail’ to the point of destination
directly or via the route you have selected and you can see how the
alarms and automatic waypoint shift all work, as if you were sailing
yourself. You can also simulate making a track trailing the ship or
plotting eventmarks, etc. as the ship is ‘sailing.
External DGPS mode - set to ON (XX34), NMEA1 or NMEA2
(XX44/54) will enable reception of DGPS data from external receiver.
The input port will switch from NMEA0183 to RTCM104 standard,
but the output will continue transmitting NMEA0183 data.
Datum:000-World Geodetic System 1984 - the internal datum is
applied if the datum line is light grey. If you wish to apply the datum
received from external unit and as such need to change the type, the
position mode must be EXTERNAL. Enter a new datum by means of
the numeric keys or the +/- keys. Refer to list of datums in Appendix B.
Dead reckoning speed - is preset to 010.0 knots, but can be increased
or decreased when DEAD RECKONING is selected as position mode.
Enter a new speed by means of the numeric keys or the +/- keys.
NMEA0183 output - see also section 8.5.1 Description of sentences.
PLOT
Go to Navigation interface - step back with [GOTO]
Input:
INTERNAL ONLY - indicates that no external source can be
selected for navigation.
NMEA0183 output - see also section 8.5.1 Description of sentences.
