GOTO
Nodes
Navigation
PLOT
Input:
Group selection: SIMRAD
Source (one available):
Simrad CE34-1 ,Sn:100003
Position mode: INTERNAL
External DGPS mode: OFF
Datum: 000-World Geodetic System1984
Dead reckoning speed: 010.0kn
NMEA0183 output:
GPS fix data: GGA ON
GNSS fix data: GNS OFF
Geographic pos, Lat/Lon: GLL OFF
Recom. min. GPS data: RMC ON
Track made good & SOG: VTG ON
Time and date: ZDA OFF
MENU
Exit Accept
ENT
Position
CE34/44/54 Setup menu Chapter 8-11
Group selection can be set to:
SIMRAD - auto-selected SimNet units from the Simrad group.
STAND-ALONE
- manually selected data source and third party units.
Source: - depending on which products (sources) are connected, the
legend will indicate: ‘none available, ‘one available, ‘multiple avail-
able’ or ‘owned, data type locked.
PLOT
Go to Position interface - step back with [GOTO]
Position mode:
INTERNAL - the applied position is compiled by the in-built GPS
receiver.
EXTERNAL - the applied position is compiled by an external unit.
DEAD RECKONING - will allow the system to function as a Navi-
gation simulator, which can be used for demonstration purpose or
for practicing ‘live’ navigation in ‘off season. If you wish to change
the preset speed (10 kn), refer to description next page.
