CP44/54 Setup menu Chapter 8-5
ENT
Confirm changes, or...
MENU
exit function without making any changes
Setup for speed:
LOG speed sensor - set to ON, the dual speed display will show
water speed from external log sensor (via ECHO port).
- set to OFF and NMEA sentence VHW set to ON, the readout will
show water speed from external water speed instrument (via NMEA
port).
LOG speed calibration - calibrate log speed readout by increasing/
decreasing the number of pulses per nautical mile - see also Appen-
dix A.
Speed alarm - can be set to maximum and/or minimum cruising
speed. This may be handy for trawl fishing, entering harbors with
speed limits, etc.
Speed stability and time of response can be adjusted in Pilot/Position
setup, press [MENU], [6], [PILOT], and use the cursor key to go to
“Speed and course filter level” to adjust the setting, confirm with
[ENT].
Press [CLR] to reset an alarm - this applies to all activated alarms in
the system.
Setup for units
Depth altitude in
- can be set to meters (m), feet (ft) or fathoms (fm).
Distance in - can be calculated in nautical miles (nm), kilometers
(km) or statue miles (mi).
Speed in - can be shown in knots (kn), kilometers/hour (kh) or
miles/hour (mh).
Temperat ure i n - can be shown in Celcius or Fahrenheit.
Software version - indicates which software version is installed in
the unit.
