Simrad CX34-DE NavStation User Manual

347 mm (13.7”)
337 mm (13.3”)
353 mm (13.9”)
365 mm (14.4”)
192 mm (7.6”) 202 mm (7.9”) 208 mm (8.2”) 220 mm (8.7”)
Installation 1 - 6 CX34/44/54 NavStation
Flush mounting of CX44
Removable corner
for flush mounting.
Minimum clearance
incl. cables: 11 cm.
Refer to included template for instructions on flush mounting.

Simrad CX34-DE NavStation Specifications

General

Brand	Simrad
Model	CX34-DE NavStation
Category	Marine GPS System
Language	English
