Simrad CX34-DE NavStation - 1.4 Installation of CX54; CX54 Mounting Options

42 (1.7”)
343 mm (13.5”)
460 mm (18.1”)
330 mm (13”)
339.2 mm (13.4”)
95 mm (3.7”)
75 mm (3.0”)
195 mm (7.7”)
CX34/44/54 NavStation Installation 1 - 7
1.4 Installation of CX54
The unit can be flat or bracket mounted - bulkhead or console.
Overhead and bulkhead mounting is only possible if using a distance piece.
Console mounting. Bulkhead mounting.
