Page #45 background imageLoading...
Page #45 background image
Fig.1
Cable inlet
Tighten the four screws
to 1.5 Nm (max)
Ship’s
heading
Logo seal on
side wall
Fig.3
Fig.2
Pull cord
White (coax)
Green (shield)
Yellow
Blue
Green
Brown
NC
White
Red
Pull cord
Blue
Green
Yellow
Violet
Pull cord 1
Orange
Red
Pull cord 1
CX34/44/54-series Installation 1-39
Interconnecting cable (DX45 + DX60) - continued
