Antenna
Shield cover
Stern side
Cable shield
Fix connector on
PCB X11, X12
Radome
(bottom)
Fixing plate
Rubber ring
Interconnection cable
Inner shield
X12 (Connect here)
Radome (bottom)
PCB
X11 (Connect here)
Installation 1-42 CX34/44/54-series
Fitting interconnection cable (RB715A):
