TR unit fixing bolts
Remove connector
Clumper
Interconnection cable
Fixing bolt
Fixing plate
Interconnection cable
Fixing bolt
Rubber
Cable inlet
5 10 mm
Washer
Fixing plate
Cable shield terminal
Scanner unit
X11
X12
Installation 1-44 CX34/44/54-series
Fitting interconnection cable (Open scanner):
