Installation 1-54 CX34/44/54-series
Alarms: Fish, max. and min. depth
Zoom mode: Shift, bottom and VRM expansion, 3 to 50 meter, feet or
fathom
Event marker: At current ping and depth memory
Picture speed: True distance or time, high, medium, low, and freeze
Noise filter: User selectable on/off
Echo pre-
sentation: A-scope and white line discrimination
Temperature: Sensor or NMEA
Speed: Sensor or NMEA
50/200kHz medium-range transducers (Airmar Des.A)
B256: 1 kW medium range transducer, 16x28° and 4x6° beams.
B45: 600 W bronze stem mount transducer, 45° and 15° beam.
B744V: 600 W bronze thru hull triducer, depth, speed and temperature,
45° and 15° beam.
P66: 600 W plastic transom mount triducer, depth, speed and temperature,
45° and 15° beam.
P319: 600 W plastic thru-hull transducer, 45° and 15° beam.
ST850: Speed and temperature only.
Dual frequency transducers (CX44/54)
Simrad 38&200, 1 kW high performance combi transducer 38 and 200 kHz,
13x21° and 7° beams.
Simrad 50&200, 1 kW high performance combi transducer 50 and 200 kHz,
10x16° and 7° beams.
Airmar B260-22, 1 kW combi transducer 50 and 200 kHz, 19° and 6° beams.
Cables included
Power cable, 2 m, 4 pin female connector, (153-5000-007), inclusive:
- power fuse T6.3A slow (5x20mm)
- fuse for DX radar scanners F8.0A fast (5x20mm)
NMEA cable, 1.5 m, 9-pin female connector (153-3002-005)
Antenna cable, 10 m RG58 (153-2025-004)
Accessories included for CX44/54
AT44 Active Tee with connector for SimNet control (153-5555-449)
