DIP SWITCH SETTINGS
20221511 / D 95
Jumper settings on IOPT board
JUMPER DEFAULT FUNCTION DESCRIPTION
J1 1-2 short Software installation Open = Software may be
installed in ICIF board
NOTE:
Control unit will be
damages if new
software is installed with
this jumper ON!
J3 1-2 short Running contact output Output port: IOPT board TB4
“RNCN”
1-2 short = Running “Closed”,
Normal “Open”
3-4 short = Running “Open”,
Normal “Closed”
NOTE:
Never use both
jumpers at the same
time!
J6 1-2 short Polarity of “LOG” signal
setting
Input port: IOPT board TB1 “L
RX”
1-2 short = Standard
3-4 short = Reversed polarity
NOTE:
If a signal not is
received with 1-2
short, 3-4 should be
set to short.
NOTE:
Never use both
jumpers at the same
time!
J7 1-2 short Polarity of “External
heading sensor” signal
setting.
Input port: IOPT board TB1
“ESRX”
1-2 short = Standard
3-4 short = Reversed polarity
NOTE:
If a signal not is
received with 1-2
short, 3-4 should be
set to short.
NOTE:
Never use both
jumpers at the same
time!
