Simrad GC80 Compact Gyro - Power Supply Unit (Option)

Simrad GC80/GC85 Compact Gyro Compass
34 20221511 / D
Power Supply Unit (Option)
FUSE NO CAPACITY TB-NO SIGNAL DESCRIPTION
F201 6.3A TB201 2AC1/2 Main power supply
F202 20A TB201 2B+/- Emergency power supply
F201 F202
Caution Make sure that power is disconnected from TB201 before any
fuses are replaced.
The fuses in the Power Supply unit are located inside a fuse
holder.
1 Open the fuse holder by pressing and turning the fuse
holder edge counter-clockwise with a screw driver.
2 Replace fuse F201 and F202, and close the holder by
turning it clockwise.
F201 (6.3A) –
F202 (20A)
TB201
