Simrad GC80 Compact Gyro - Tb2

TERMINAL LAYOUT
20221511 / D 85
PIN NO NAME DETAILS
34 2TX+
35 2TX-
Serial signal output
36 2TSC Serial signal common
37 2R24- Serial repeater power supply (24V DC common)
38 2R24+ Serial repeater power supply (24V DC)
39 3TX+
40 3TX-
Serial signal output
41 3TSC Serial signal common
42 3R24- Serial repeater power supply (24V DC common)
43 3R24+ Serial repeater power supply (24V DC)
44 4TX+
45 4TX-
Serial signal output
46 4TSC Serial signal common
47 4R24- Serial repeater power supply (24V DC common)
48 4R24+ Serial repeater power supply (24V DC)
TB2
When used with Simrad Power supply unit (OPTION):
PIN NO NAME DETAILS
1 24R+ Power unit 24R input
2 24R- Power unit 24RC input
3 PF
4 POC
5 POV
6 PC
Power unit alarm input
7 SWV Not used
8 SW+ Power unit switch signal
9 SW- Not used
10 GRX+
11 GRX-
GPS serial signal input
12 SL+
13 SL-
LOG contact signal input
14 FGND Earth
15
16
Not used
