CHECK THE PARTS
Pedestal
1 2 3 4
6
a
b
c
d
e
7
8
5
1
Radar pedestal
2
Interconnection cable 20 m (65 ft). Other lengths are available from your nearest Simrad
®
dealer.
3
Lifting strap
4
5
Tef-Gel anti-seize, anti-corrosion gel
6
Mounting bolts and washers
x 4
x 4
x 4
x 4
e) Plastic isolating washer, M12 x 38 x 8
7
Mounting template
8
This manual
