Installation | HS80/HS80A/MX575C/MX575D User Manual
Received messages based on a request
PG No.
(PGN)
Description Level
Default Update
Rate (msec)
Freq
(Hz)
059392 ISO Acknowledgement
Used to acknowledge the status of certain
requests addressed to a specific ECU.
B On Request On
Request
059904 ISO Request
Request the transmission of a specific PGN,
addressed or broadcast.
B On Request On
Request
060928 ISO Address Claim
Used to identify to other ECUs the address
claimed by an ECU.
B On Request On
Request
126996 Product Information
NMEA 2000 database version supported,
manufacturer’s product code, NMEA
2000 certification level, Load Equivalency
number, and other product- specific
information.
B On Request On
Request
126464 Receive/Transmit PGNs group function
The Transmit / Receive PGN List Group
type of function is defined by first field.
The message will be a Transmit or Receive
PGN List group function.
B On Request On
Request
129538 GNSS Control Status
GNSS common satellite receiver parameter
status.
B On Request On
Request
129545 GNSS RAIM Output
Used to provide the output from a GNSS
receiver’s Receiver Autonomous Integrity
Monitoring (RAIM) process. The Integrity
field value is based on the parameters set
in PGN 129546 GNSS RAIM Settings.
B On Request On
Request
129546 GNSS RAIM Settings
Used to report the control parameters for
a GNSS Receiver Autonomous Integrity
Monitoring (RAIM) process.
B On Request On
Request
The next section shows the transmitted PGNs with their default update rate with the Smart
GPS compass in NMEA 2000 mode.
Transmitted messages
PG No.
(PGN)
Description
Level Default Update
Rate (msec)
Freq
(Hz)
126992 System Time
The purpose of this PGN is twofold: To
provide a regular transmission of UTC
time and date. To provide synchronism for
measurement data.
B 1000 1
127250 Vessel Heading
Heading sensor value with a flag for True or
Magnetic. If the sensor value is Magnetic,
the deviation field can be used to produce
a Magnetic heading, and the variation
field can be used to correct the Magnetic
heading to produce a True heading.
B 100 10
