17
Operating the display | MO Series User Manual
Option Sub option Setting Function
Scaling HDMI-1 1:1, FILL, ASPECT Sets input image to true size, ll
available screen area, or to ll screen
vertically or horizontally but maintain
correct aspect ratio
DVI-2
VID-3
VID-4
Option Sub option Range Description
Colour Temperature User, 6500K,
9300K
Allows the user to select colour temperature.
The 6500K setting makes the display colour
warmer (slight red tint). The 9300K setting
makes the display colour cooler (slight blue
tint). The User setting allows the customer to
manually select the Red, Green, and Blue values
Red 0 - 255 Adjusts the red colour
Green Adjusts the green colour
Blue Adjusts the blue colour
Option Sub option Setting/Range Description
PIP Control
(Picture-in-
Picture)
PIP Mode OFF, PIP, Split Sets to either no PIP, regular PIP as dictated by
following settings, or 50:50 split pane (image
scaled to t)
PIP Swap Swaps main source with PIP source
PIP Size Small,
Medium,
Large
controls PIP window size. Sets to
approximately 1/6th, 1/5th, and 1/4 of screen
area respectively
PIP
Horizontal
0-100 adjusts horizontal position, where 0 = left, and
100 = right
PIP Vertical 0-100 adjusts vertical position, where 0 = bottom,
and 100 = top
Option Sub option Setting/Range Description
Source Main Source HDMI-1, DVI-2,
VID-3, VID-4
Select which physical input should be
displayed
Note: PIP source can only be set to VID-3
or VID-4 when HDMI or DVI are the main
source. The reverse applies when either of
the analogue sources is set as main source
PIP Source
Option Sub option Range Description
OSD
Position
Horizontal 0-100 adjusts horizontal position, where 0 = left, and 100 =
right
Vertical adjusts vertical position, where 0 = left, and 100 = right
Option Sub option Description
Language English
French
German
Spanish
Italian
Portuguese
Select language best suited for OSD text
