General specications | MO Series User Manual
General specications
LCD display 15.6” TFT Active Matrix
Panel
18.5” TFT Active Matrix
Panel
24” TFT Active Matrix
Panel
Weight (monitor only): MO16P=3.33 kg
MO16T = 3.60 kg
MO19P = 4.30 kg
MO19T = 4.60 kg
MO24P = 6.63 kg (14.64
lbs)
MO24T = 7.04 kg
(15.52lbs)
Brightness Touch models :
>1000nit
Pilot models: >300nit
Screen glass AF, IR (‘T’ models)
AF, AR (‘P’ models)
Native resolution MO16: 1366x768
MO19: 1366x768
MO24: 1920x1080
Protection thermal: auto screen
dimming, overvoltage,
reverse polarity, low
voltage
Contrast MO16: 500:1
MO19: 1000:1
MO24: 5000:1
Power and setup keys capacitive touch
View angle Horizontal: All 80/80.
Vertical:
MO16/19, top 20,
bottom 70.
MO24, 80/80.
Comms / Control RS422, USB, NMEA 2000
Display colours 16.7 million Video inputs 1x HDMI, 1x DVI-I, 2x
composite (NTSC & PAL)
Operating temp -15 to +55 degrees
Celcius
Picture in Picture YES; variable position
& size
Non operating temp -20 to 60 degrees
Celcius
Auto video detection YES
Operable humidity 95% Auto video scaling YES
Water ingress resistance IPX2 (bracket mount)
IPX5 (dash mount - front
only exposed)
Supply voltage 12V / 24V DC (9-31.2V)
Bezel & rear case PC/ABS Power consumption Touch: 24W, 25W, 65W
Pilot: 12W, 13W, 30W
Supported Resolutions
640 x 480
(8-32 bit colour, 59, 60 Hz)
720 x 480
(8-32 bit colour, 59, 60 Hz)
720 x 576
(16-32 bit colour, 50-60 Hz)
800 x 480
(8-32 bit colour, 60 Hz)
800 x 600
(8-32 bit colour, 60 Hz)
1024 x 600
(8-32 bit colour, 60 Hz)
1024 x 768
(8-32 bit colour, 60 Hz)
1280 x 768
(8-32 bit colour, 60 Hz)
1280 x 720
(8-32 bit colour, 50-60 Hz)
1360 x 768
(8-32 bit colour, 60 Hz)
1366 x 768
(8-32 bit colour, 60 Hz)
1920 x 1080
(8-32 bit colour, 50-60 Hz)
1920 x 1080
(8-32 bit colour, 25, 29, 30
Hz Interlaced)
¼ Note: Occassionally specications may change - refer to the latest edition of the manual on
the website: www.simrad-yachting.com
