Introduction
The Simrad MO Series monitors oer a low prole, high brightness solution for displaying
video from a variety of sources. The range includes six models; the 16”, 19”, and 24” Touch
series, and the 16”, 19” , and 24” Pilot series. The Touch models are suited to both indoor
and outdoor (direct sunlight) use, whereas the Pilot series are suited to enclosed helm
installations. The Pilot series do not utilize a touchscreen, therefore when connected to a
Marine Processor, require an external controller such as the OP40. All monitors in the range
accept video via HDMI, DVI-I and composite inputs.
Items included
1
2
18
12
13
17
16
10
19
20
3
4
5
9
8
6
7
11
15
14
21
1 Monitor
2 Dash mount brackets (x2)
3 Washer, M4, 12 mm, SS (x4)
4 Pozi pan head machine screw, M4 x 12 mm, SS (x4)
5 Plastic spacer (x4)
6 Wing nut M5 (x4)
7 Wing head machine screw (x4)
8 Plastic stopper - dash mount (x4)
9 Pozi pan head self-tapping screw 4G x 1/2” (x12)
10 Cable retention bracket with screws 4G x 1/2” (x4)
11 Cable ties (x4)
12 Connector block (serial data)
13 Micro-C tee piece
14 Micro-C cable, 2 m (6ft)
15 Power cable with connector
16 Bezel trim, black (x2)
17 Bezel trim, silver (x2)
18 Operator manual
19 Cutout template
20 Warranty card
21 Drill and screw guide tool
